1/4" Male BSP tapered R series X KF25 Flange stainless steel vacuum adapter

Product Description
$15.00
Maximum quantity available reached.

Brand new item

  • Male BSP R series or PT 1/4" x KF25 Flange Stainless Steel 304 Vacuum adapter

  • 19 thread per inch

  • 55 ° thread angle

  • tapered thread / self sealing with telfon tape or liquid sealant

  • with HEX nut for easy tigthening

  • PT / BSP-T / R Threads is commonly used in Europe, Austrialia, UK, Japan and China

  • End to End Length 4cm


Adapter KF-25 to 1/4" Male BSP-Tapered R series adapter, Flange Size ISO-KF NW-25, Stainless Steel

These adapters are KF-25 to 1/4" BSPT PT Male pipe thread. They are commonly used to make connections between ISO-KF and BSPT-Female pipe. The ISO-KF flanges are often called quick flange fittings because they are quick to assemble. A circumferential clamp and centering ring form the vacuum seal between the connecting flanges (please see top right figure - click to enlarge). The centering ring contains a rubber elastomer o-ring. The standard sizes for quick flange fittings are KF-10, KF-16, KF-25, KF-40, and KF-50 with flange sizes NW-10, NW-16, NW-25, NW-40, and NW-50, respectively. They are made of corrosive resistant stainless steel.

Sku: MBSP-R-KF25-2
