CROSS, 4 X KF25 FLANGE - Normal Grade

Product Description
$26.00
Maximum quantity available reached.
  • Brand new
  • Normal grade KF-25 4-ways Cross adapter follow ISO-KF standards and have a flange size of NW-25.
  • Made of Stainless steel 304




More Info:

They are commonly used to build foreline vacuum plumbing and process systems. They are often called quick flange fittings because they are quick to assemble. A circumferential clamp and centering ring form the vacuum seal between the connecting flanges (please see top right figure - click to enlarge). The centering ring contains a rubber elastomer o-ring. The standard sizes for quick flange fittings are KF-10, KF-16, KF-25, KF-40, and KF-50 with flange sizes NW-10, NW-16, NW-25, NW-40, and NW-50, respectively.



KF-25 4-Way Cross
ISO-KF Flange Size: NW-25, KF-25
Common Dimensions: B=1.97" (50mm), A=3.94" (100mm)

Sku: CROSS-KF25
